| Slider Bed |
 View |
| McKessock's #1 Selling Belt Conveyor |
| TA |
Medium Duty |
6" to 24" belts on top of slider bed |
ta.pdf |
 |
| McKessock's Favourite Belt Conveyor |
| TR |
Medium Duty |
6" to 30" belts on top of slider bed-troughed bed |
tr.pdf |
| TL |
Heavy Duty |
24" to 52" belts on top of slider bed |
tl.pdf |
| SB |
Medium Duty |
10" to 54" belts on top of slider bed |
sb.pdf |
| HDSB25 |
Heavy Duty - for difficult service (eg. auto parts & metal
stamping, etc.) |
12" to 72" wide belts on top of slider bed |
HDSB.pdf |
| TH |
Trash Belt |
12" to 54" belts on top of slider bed-trash handling |
th.pdf |
| MDCSW |
Medium Duty - Wide (V-Guided option on short wide conveyors) |
42" to 72" belts on top of slider bed (v-guided belt tracking optional) |
MDCSW.pdf |
| TS-4100-100 |
Medium Duty - (Beaded Edge-Guided Belts) |
12" to 162" wide x very short 18" overall length |
TS4100-100.pdf |
| TS-1900P-1500R |
Light Duty |
Gravity Spiral Chutes for Floor-to-Floor transfers |
TS1900P-1500R.pdf |
| TS-1500-22 |
Light Duty - (Beaded Edge-Guided Powered Belt Curves) |
12" to 162" wide x very short 18" overall length |
TS1500-22.pdf |
| TS-1500-100 |
Belt Curve - Premium |
10" to 18" belts on top of slider bed-endless belt |
ts1500-100.pdf |
| TS-1500-140 |
Belt Curve - Premium |
20" to 48" belts on top of slider bed-endless belt |
ts1500-140.pdf |
| MDBC |
Belt Curve - Standard |
10" to 36" belts on top of slider bed-laced belt |
MDBC.pdf |
| Gapper |
Carton
Gapping |
gapper.pdf |
| Gapper-L |
Carton
Gapping |
gapperl.pdf |
| |
|
|
|
| Roller Bed |
|
View |
| RB |
Medium Duty - 1.9" rollers |
10" to 54" wide belts on top of roller bed |
rb.pdf |
| MDRB |
Medium Duty - 1.9" rollers |
12" to 48" wide belts on top of roller bed |
MDRB.pdf |
| HDRB25 |
Heavy Duty - 2.5" rollers - for difficult service (eg. auto
parts & metal stamping, etc.) |
12" to 72" wide belts on top of roller bed |
HDRB25.pdf |
| CRB |
Troughed Belt |
12" to 30" wide belts for bulk handling |
crb.pdf |
| |
|
|
|
| Live Roller |
|
View |
| 190-LR |
Medium Duty - Flat Belt |
13" to 39" between rails with 1.9" roller diameters |
190lr.pdf |
| 138-NSP |
Light Duty - Spool |
10" to 22" between rails with 1-3/8" roller diameters |
138nsp.pdf |
| 138-NSPC |
Light Duty - Spool Curve |
10" to 22" between rails with 1-3/8" roller diameters |
138nspc_nsps_nspss.pdf |
| 138-NSPS |
Light Duty - Spool Curve Spur |
10" to 22" between rails with 1-3/8" roller diameters |
138nspc_nsps_nspss.pdf |
| 138-NSPSS |
Light Duty - Spool Straight Spur |
10" to 22" between rails with 1-3/8" roller diameters |
138nspc_nsps_nspss.pdf |
| 190-NSP |
Medium Duty - Spool |
13" to 39" between rails with 1.9" roller diameters |
190nsp.pdf |
| 190-NSPC |
Medium Duty - Spool Curve |
13" to 39" between rails with 1.9" roller diameters |
190nspc_nsps_nspss.pdf |
| 190-NSPS |
Medium Duty - Spool Curved Spur |
13" to 39" between rails with 1.9" roller diameters |
190nspc_nsps_nspss.pdf |
| 190-NSPSS |
Medium Duty - Spool Straight Spur |
13" to 39" between rails with 1.9" roller diameters |
190nspc_nsps_nspss.pdf |
| 190-PR |
Light Duty - Spool - 24vDC Motorized Rollers -
Compact vertical height fits tight spots |
17" to 39" between rails with 1.9" roller diameters |
190pr_prc.pdf |
| 190-PRC |
Light Duty - Spool Curve - 24vDC Motorized Rollers -
Compact vertical height fits tight spots |
17" to 39" between rails with 1.9" roller diameters |
190pr_prc.pdf |
| 190-E24 |
Medium Duty - Spool - 24vDC - Quiet drives, less
maintenance |
9" to 39" between rails with 1.9" roller diameters |
190e24.pdf |
| 190-E24C |
Medium Duty - Spool - 24vDC - Quiet drives, less
maintenance |
9" to 39" between rails with 1.9" roller diameters |
190e24.pdf |
| |
|
|
|
| Accumulating - Minimum Pressure |
|
View |
| 138-ACC |
Light Duty - V-Belt |
10" to 22" between rails with 1-3/8" roller diameters |
138acc.pdf |
| 138-LRC |
Light Duty - V-Belt Straight Roller Curve |
10" to 22" between rails with 1-3/8" roller diameters |
138lrc_lrct.pdf |
| 138-LRCT |
Light Duty - V-Belt Tapered Roller Curve |
10" to 22" between rails with 1-3/8" roller diameters |
138lrc_lrct.pdf |
| 138-LRS |
Light Duty - V-Belt Spur |
10" to 22" between rails with 1-3/8" roller diameters |
138lrs.pdf |
| 138-LRSS |
Light Duty - V-Belt Straight Spur |
10" to 22" between rails with 1-3/8" roller diameters |
138lrss.pdf |
| 190-ACC |
Medium Duty - V-Belt |
13" to 39" between rails with 1.9" roller diameters |
190acc.pdf |
| 190-LRC |
Medium Duty - V-Belt Tapered Roller Curve |
13" to 39" between rails with 1.9" roller diameters |
190lrc.pdf |
| 190-LRS |
Medium Duty - V-Belt Spur |
13" to 39" between rails with 1.9" roller diameters |
190lrs.pdf |
| 190-LRSS |
Medium Duty - V-Belt Straight Spur |
13" to 39" between rails with 1.9" roller diameters |
190lrss.pdf |
| 190-ACZ |
Medium Duty - Flat Belt |
13" to 39" between rails with 1.9" roller diameters |
190acz.pdf |
| |
|
|
|
| Accumulating - Zero Pressure - EZLogic - Gen3 |
View |
| 138-NSPEZ |
Light Duty - Spool |
10" to 22" between rails with 1-3/8" roller diameters |
138nspez.pdf |
| 190-NSPEZ |
Medium Duty - Spool |
13" to 39" between rails with 1.9" roller diameters |
190nspez.pdf |
| 190-NSPEZC |
Medium Duty - Spool Curve |
13" to 39" between rails with 1.9" roller diameters |
190nspezc.pdf |
| Hytrol's #1 Selling Zero-Pressure Conveyor |
| ABEZ |
Medium Duty - Flat Belt |
13" to 39" between rails with 1.9" roller diameters |
abez.pdf |
|
| 190-PREZ |
Light Duty - Spool - 24vDC Motorized Rollers - Compact vertical
height fits tight spots |
17" to 39" between rails with 1.9" roller diameters |
190prez_prezc.pdf |
| 190-PREZC |
Light Duty - Spool Curve - 24vDC Motorized Rollers - Compact
vertical height fits tight spots |
17" to 39" between rails with 1.9" roller diameters |
190prez_prezc.pdf |
| 199-CREZD |
Medium Duty - Chain-to-Chain Driven Rollers |
12.25" to 36.25" conveying surface width - 1.9" heavy-wall roller diameters |
199crezd.pdf |
| 25-LREZ |
Heavy Duty - Belt Driven Rollers |
39" to 85" between rail width - 2.5" roller diameters |
25lrez.pdf |
| 25-CREZD |
Heavy Duty - Chain-to-Chain Driven Rollers |
27.75" to 63.75" conveying surface width - 2.5" roller diameters |
25crezd.pdf |
| CDZA25 |
Heavy Duty - Chain-to-Chain Driven Rollers - Pneumatic zone
clutches in lieu of EZLogic |
6" to 61" coneying surface width - 2.5" roller diameters |
CDZA25.pdf |
| ZPLR25 |
Heavy Duty - Belt Driven Rollers - 24vDC sensors in lieu of
EZLogic |
39" to 84" between rail width - 2.5" roller diameters |
ZPLR25.pdf |
| 36-CREZD |
Very Heavy Duty - Chain-to-Chain Driven Rollers |
27.75" to 63.75" conveying surface width - 3.5" roller diameters |
36crezd.pdf |
| CCEZ |
Case Conveyor for Beverage Cans |
ccez.pdf |
| CCAC |
Case Conveyor Curve |
ccac.pdf |
| DCEZ-60 |
Heavy Duty
Horizontal Chain for Pallet Transfer |
2-strands #60 chain |
dcez60.pdf |
| DCEZ-63 |
Heavy Duty
Horizontal Chain for Pallet Transfer |
3-strands #60 chain |
dcez63.pdf |
| DCEZ-82 |
Heavy Duty
Horizontal Chain for Pallet Transfer |
2-strands #80 chain |
dcez82.pdf |
| DCEZ-83 |
Heavy Duty
Horizontal Chain for Pallet Transfer |
3-strands #80 chain |
dcez83.pdf |
| PLEZD |
Heavy Duty Plastic Belt for Pallets with "Unconveyable" Irregular Bottoms |
plezd.pdf |
| 190-E24EZ |
Medium Duty - Spool - 24vDC - Quiet drives, less
maintenance |
9" to 39" between rails with 1.9" roller diameters |
190e24ez.pdf |
| 190-E24EZC |
Medium Duty - Spool Curve - 24vDC - Quiet drives,
less maintenance |
9" to 39" between rails with 1.9" roller diameters |
190e24ez.pdf |
| |
|
|
|
| Chain Roller - CDLR |
|
View |
| 199-CRR |
Medium Duty - Chain-to-Chain Driven Rollers |
12.25" to 36.25" conveying surface width - 1.9" heavy-wall roller diameters |
199crr.pdf |
| 199-CRRC |
Medium Duty - Chain-to-Chain Curve |
12.25" to 36.25" conveying surface width - 1.9" heavy-wall roller diameters |
199crrc.pdf |
| McKessock's #1 Selling CDLR Conveyor |
| 25-CRR |
Heavy Duty - Chain-to-Chain Driven Rollers |
27.75" to 63.75" conveying surface width - 2.5" roller diameters |
25crr.pdf |
| 26-CRR |
Heavy Duty - Chain-to-Chain Driven Rollers |
27.75" to 63.75" conveying surface width - 2.625" heavier rollers |
26crr.pdf |
| 25/26-CRRC |
Heavy Duty - Chain-to-Chain Driven Curve |
27.75" to 63.75" conveying surface width - 2.5" roller diameters |
25_26crrc.pdf |
| 25-CRRCT |
Heavy Duty - Chain-to-Chain Driven Tapered Curve |
27.75" to 63.75" conveying surface width - 2.5" roller diameters |
25crrct.pdf |
| CDDB25 |
Heavy Duty - Chain-to-Chain Driven Rollers - Dual chain box -
Very close to 2.812" roller centers |
6" to 61" conveying surface width - 2.5" roller diameters |
CDDB25.pdf |
| 36-CRRH |
Very Heavy Duty - Chain-to-Chain Driven Rollers |
27.75" to 63.75" conveying surface width - 3.5" roller diameters |
36crrh.pdf |
| |
|
|
|
| Miscellaneous Conveyors |
|
View |
| SL |
Heavy Duty
Horizontal Slats |
sl.pdf |
| DC-60 |
Heavy Duty
Horizontal Chain for Pallet Transfer |
2-strands #60 chain |
dc60.pdf |
| DC-63 |
Heavy Duty
Horizontal Chain for Pallet Transfer |
3-strands #60 chain |
dc63.pdf |
| DC-82 |
Heavy Duty
Horizontal Chain for Pallet Transfer |
2-strands #80 chain |
dc82.pdf |
| DC-83 |
Heavy Duty
Horizontal Chain for Pallet Transfer |
3-strands #80 chain |
dc83.pdf |
| MSCC |
Multi-Strand Chain Conveyor |
2, 3 or 4 strands #80 chain |
MSCC.pdf |
| TW |
Wire Mesh Belt |
tw.pdf |
| WC |
Wire Mesh Belt
Curve |
wc.pdf |
| PSB |
Plastic Belt |
psb.pdf |
| PSBC |
Plastic Belt
Curve |
psbc.pdf |
| |
|
|
|
| Inclined |
|
View |
| C |
Floor-to-Floor Slider Bed - Roughtop Belt with Button Cleats for Steeper Inclines |
14" to 30" belt widths |
c.pdf |
| SBI |
Floor-to-Floor Slider Bed |
10" to 36" belt widths |
sbi.pdf |
| FTFSB |
Floor-to-Floor Slider Bed |
12" to 36" belt widths |
FTFSB.pdf |
| RBI |
Floor-to-Floor Roller Bed |
10" to 36" belt widths |
rbi.pdf |
|
| |
|
|
|
| Portables |
|
View |
| A |
Portable Aluminum Slider Bed |
10" belt |
a.pdf |
| R |
Portable Aluminum Slider Bed with Folding Device |
12" belt |
r.pdf |
| B |
Portable Steel Slider Bed with Portable Base, folding device and self-powered raising device |
14" belt |
b.pdf |
| BL |
Portable Steel Slider Bed with Portable Base, folding device and self-powered raising device |
14" belt |
bl.pdf |
| BA |
Portable Steel Slider Bed with Portable Base, folding device and self-powered raising device |
14" belt |
ba.pdf |
| PC |
Portable Parts Conveyor - Slider Bed with Portable Base |
4" to 24" belt widths |
pc.pdf |
| PCX |
Portable Parts Conveyor - Slider Bed with Horizontal and Inclined Sections & Portable Base |
12" to 24" belt widths |
pcx.pdf |
| PCH |
Heavy Duty Piano Hinged Parts Conveyor |
6" to 24" belt widths |
pch.pdf |
| PCA |
Parts - Light Duty - Low Profile |
4" to 18" belt widths |
pca.pdf |
| |
|
|
|
| Gravity |
|
View |
| Skatewheel Straight |
sw_aw.pdf |
| Skatewheel Curve |
swc_awc.pdf |
| Skatewheel Spur |
sws_aws.pdf |
| Skatewheel Flexible/Extendible
"FX-200" Heavy Duty |
fx200.pdf |
| Roller
1 in. Dia. x 11 Ga. |
Light-Duty & Close Roller Spacing. Problem Solver for Small Items |
Lewco1011.pdf |
Roller 1-3/8 in. Dia. x 18 Ga.
|
Standard Duty, Straight |
ssr_sar.pdf |
Roller 1-3/8 in. Dia. x 18 Ga.
|
Standard Duty, Curve (Straight or Tapered Rollers) |
ssrc_sarc.pdf |
Roller 1-3/8 in. Dia. x 18 Ga.
|
Standard Duty, Spur |
ssrs_sars.pdf |
| Roller
1-3/8 in. Dia. x 16 Ga. |
Heavy Duty, Straight. Problem Solver used with 1.5" centers for skids with "unconveyable" protrusions. |
1416.pdf |
| McKessock's #1 Selling Gravity Conveyor |
Roller 1.9 in. Dia. x 16 Ga
Roller 1.9 in. Dia. x 9 Ga. |
Straight |
19sr_gsr.pdf |
|
Roller 1.9 in. Dia. x 16 Ga
Roller 1.9 in. Dia. x 9 Ga. |
Curve - Straight Rollers |
19src_gsrc.pdf |
|
| Roller 1.9 in. Dia. x 9 Ga. |
Curve - Straight Rollers |
199src.pdf |
| Roller 1.9 in. Dia. x 16 Ga. |
Curve - Tapered Rollers |
19srct.pdf |
Roller 1.9 in. Dia. x 16 Ga
Roller
1.9 in. Dia. x 9 Ga. |
Spur |
19srs_gsrs.pdf |
|
Roller 2.0 in. Dia. x 12 Ga.
Roller
2-1/2 in. x 14 Ga. |
Straight |
20sr.pdf |
Roller 2.0 in. Dia. x 12 Ga.
Roller
2-1/2 in. x 14 Ga. |
Curve - Straight Rollers |
20src.pdf |
Roller 2.0 in. Dia. x 12 Ga.
Roller
2-1/2 in. x 14 Ga. |
Spur |
20srs.pdf |
Roller
2-1/2 in. Dia. x 11 Ga.
Roller 2-5/8 in. Dia. x 7 Ga. |
Straight |
25sr-26sr.pdf |
Roller
2-1/2 in. Dia. x 11 Ga.
Roller 2-5/8 in. Dia. x 7 Ga. |
Curve - Straight Rollers |
25src.pdf |
Roller
2-1/2 in. Dia. x 11 Ga.
Roller 2-5/8 in. Dia. x 7 Ga. |
Curve - Tapered Rollers |
25src.pdf |
Roller
2-1/2 in. Dia. x 11 Ga.
Roller 2-5/8 in. Dia. x 7 Ga. |
Spur |
25srs.pdf |
| Roller 3-1/2 in. Dia. x 9 Ga. |
Heavy Duty Straight |
35sr.pdf |
| Roller 3-1/2 in. Dia. x .300 in. |
Very Heavy Duty Straight |
36sr.pdf |
Conveyor Rails & Skatewheel
Rails
Types 1 / 2 / 3 / 4 / 5 |
65# Wheels, 1/8" Frames |
conveyorrails.pdf |
Conveyor Rails & Skatewheel
Rails
Types WRA / WRB / WRC / WRD / WRE / WRF / WRG / WRH / WRK / WRL |
75# Wheels, 1/8" Frames |
wheelrail.pdf |
Conveyor Rails & Skatewheel Rails
Flow & Pallet Rail |
290# Wheels, 3/16" Frames |
flow_palletrail.pdf |
| |
|
|
| Accessories |
|
View |
| Ball Transfer Tables - 75# & 250# balls - Type BPA / BPAS / BPB / BPBS / BPC / BPCS / BPD / BPDS |
balltransfer.htm |
| Ball Transfer Tables - 50# balls - Type BTT |
btt.pdf |
| Diverter - Pivot - Double Powered |
dppd.pdf |
| Diverter - Pivot - Single Powered |
overheadpush_singleppd.pdf |
| Gates |
gates.pdf |
| Guard Rails |
guardrails.pdf |
| Package Stops A - For Hytrol Products - Non-powered |
packagestops_turning_wheel.pdf |
| Package Stops B - For Hytrol Products - Non-powered
and pneumatic |
packagestops.htm |
| Package Stops C - For Lewco Products - Non-powered |
end.pdf |
| Package Stops D - For Lewco Products - Pneumatic
blade stop |
PUBS.pdf |
| Package Stops E - For Lewco Products - Pneumatic
roller brake |
RBB.pdf |
| Plows - Manual & Pneumatic |
turntables_plow.pdf |
| Pusher - 50/50 High Speed Pusher for Reduced Floor Space
- 50 Cartons per minute |
prosort5050.pdf |
| Pusher - High Speed - 45 Cartons per minute |
ldp_hsp.pdf |
| Pusher - Light Duty |
ldp_hsp.pdf |
| Pusher - Overhead Push-Off |
overheadpush_singleppd.pdf |
| Supports - Floor Supports |
floorsupports.pdf |
| Supports - Floor Support Casters |
floorsupports.pdf |
| Supports - Poly-Tier Supports & Ceiling Hangers |
polytier_ceilinghanger.pdf |
| Supports - Portable Castered Supports, Tripod Stand, Roller Stand |
pcs_ts_rts.pdf |
| Traffic
Cop |
yswitch_scs_trafficcop.pdf |
| Transfer - Pop-Up Type - BR-1500# & BR-3000# Chain Transfer |
chain_transfers.pdf |
| Transfer - Pop-Up Type - CC-1500# & BR-3000# Chain Transfer |
chain_transfers.pdf |
| Transfer - Pop-Up Type - CT-200# & CT-300# Chain Transfer |
oring_revoring.pdf |
| Transfer - Pop-Up Type - ET-1500# & BR-3000# Chain Transfer |
chain_transfers.pdf |
| Transfer - Pop-Up Type - O-Ring Transfer |
oring_revoring.pdf |
| Transfer - Pop-Up Type - Reversing O-Ring Transfer |
oring_revoring.pdf |
| Transfer - Pop-Up Type - Very Heavy Duty 3.5" Roller Transfer |
35rollertrans.pdf |
| Transfer - Pop-Up Type - Light Duty Non-Powered 1.9"
Roller Transfer for gravity conveyors |
Lewco Pop-up Gravity Transfer ref W9605.pdf |
| Transfer Car - Manual |
tc-manual.pdf |
| Transfer Car - Powered |
tc-powered.pdf |
| Transfer Car - Powered |
TCP.pdf |
| Transfer Car - Manual - Pass Thru |
Pttc19.pdf |
| Turning Wheels |
packagestops_turning_wheel.pdf |
| Turntables - 26-CRPT Turntable - Powered Rotate with Powered 25-CRR (CDLR) on top |
35rollertrans.pdf |
| Turntables - LP360 Powered Rotate Turntable - 360° rotation |
LP360.pdf |
| Turntables - PP90 Powred Rotate Turntable - 90° rotation |
PP90.pdf |
| Turntables - LPTG19/LPTG25 Gravity Turntable |
LPTG.pdf |
| Turntables - LPT Low Profile
Gravity Turntable |
LPT.pdf |
| Turntables - Light Duty - Powered & Manually Operated |
turntables_plow.pdf |
| Walkover Plates - Requires Workplace Safety Check by
oters |
walkover-plates.pdf |
| Y-Switch |
yswitch_scs_trafficcop.pdf |
| |
|
|
| Information Sheets |
|
View |
| Information Sheet to be filled out with requests for quotation. Includes wood pallet selection diagrams |
app_info_sheet.pdf |
| EZ-Logic Zero Pressure Application Guide Lines |
zero_pressure_application.pdf |
| EZ-Logic Gen3 Component Sheet |
ezlogic_components.pdf |
| Incline Lift Angle Guide - For use when calculating incline angles. |
incline_lift_guide.pdf |
| Undertrussing Information - For use when spanning gaps over 10' without supports. |
undertrussing.pdf |
| |
|
|
| Sortation |
|
View |
| ProSort 45 |
Pivoting Arm Sorter - 40 cartons per minute |
prosort45.pdf |
| ProSort 50/50 |
See Pusher - 50/50 above |
|
| ProSort 60 |
Pivoting Arm Sorter - 60 cartons per minute |
prosort60.pdf |
| ProSort 131 |
High Speed Shoe Sorter - Small Items |
prosort131.pdf |
| ProSort 421 & 431 |
High Speed Shoe Sorter - Larger Cartons |
prosort421_431.pdf |
|
| ProSort
SC1 & SC2 |
Horizontal Belt & Diverter Sorter |
prosortSC1_SC2.pdf |
| ProSort SRT - Small Roller Transfer |
Two sided diverts. High rates of speed. Multiple narrow belts.
Divert rollers pop-up between belts. |
prosort_srt.pdf |
|
| Vipersort |
Right Angle Sortation - 120 small items per minute |
vipersort.pdf |
| |
|
|
