Model SW/AW is used to carry lightweight
cartons & packages. Requires less slope & maintains product
orientation on curves. Straight sections & curved sections available.
Sideframes: 2-1/2" deep x 12 Ga. formed steel powder painted.
Standard sections come in lengths of
5' & 10' but intermediate lengths available in 3"
increments from 12" to 120".
Standard overall frame widths: 12",
15", 18" &
24" but custom widths available
to 30".
Wheels: 1-15/16" OD with 1/4" diameter bare steel axles
on 3" or 4" axle centers
Capacity-up to 65 lbs. per wheel. (Refer to chart in catalogue sheets attached)
